Victron Quattro 48/10000/140- 100/100

Reference: VIC-QUATTRO-48-10000-140-100-100

Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple system integration features such as three or split phase operation and parallel operation.

Need help? Email us: support@solar-shop.co.za

Download Data Sheet

More details

10 Item Items

In Stock

1 question about the product

More info

Two AC Inputs & two AC Outputs

The Quattro can be connected to two independent AC sources, for example shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

Unique PowerAssist feature

The Quattro will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.

Virtually unlimited power thanks to parallel operation

Up to 6 Quattros can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities.

Remote Monitoring and Control

Monitor and control your Quattro and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for hire vehicles and more...

Questions

Send us your question

Hein van Zyl on 08/09/2019	Question: Can I use this Quattro inverter as off-grid (island) system & is it possible to automatically switch to a generator in case batteries run out. Is it possible to connect 16000W (40x400W) of panels to this inverter? I need only 8000W, but I need 16000W total because winter solar harvesting is only half of what I can harvest in summer at my location.
	Answer: Hi Hein. The Victron Quattro is just an inverter with an AC charger. You would need to buy MPPT's and other components in order to do what you want to do.
